NEW! SMART DIALER- IoT - THE BRAND NEW UNIVERSAL GSM COMMUNICATOR FOR REMOTE CONTROL OF BARRIERS AND AUTOMATIC GARAGE ELECTRIC DOORS
IoT REMOTE CONTROL via cloud system (CLOUD), WEB and mobile devices - unlimited number of users
✔ Quick setup for a minute via cloud system (CLOUD) by mobile or computer, or by SMS commands
✔ FREE application for iOS и Android
✔ FREE software for set-up and configuration
✔ 3 modes output - pulse, trigger and indicator
✔ Compatible with all mobile operators all over the world>
✔ Notifies UNLIMITED NUMBER OF USERS Via cloud system (CLOUD
✔ UP TO 500 USERS after authorization via device SMART DIALER-IoT can control - barrier, gate, door by call (VOICE CALL) and / or SMS from a mobile phone
Purpose of Use
The last generation universal GSM communicator SMART DIALER-IoT is used for REMOTE CONTROL TO OPPEN and/or TO CLOSE of barriers and automatic gates, garage doors or electric doors via various mobile devices.
Quick setup for a minute via cloud system (CLOUD) whiteout need to go to the place where the device is installed. This saves a lot of time and additional costs for installers!!!
Functionality
- UNLIMITED NUMBER OF USERS Via cloud system (CLOUD) can OPPENED/CLOSSED door or barrier or to be notified for these event.
- UP TO 500 USERS after authorization via device SMART DIALER-IoT can control - barrier, gate, door by call (VOICE CALL) and / or SMS from a mobile phone.
- Five users can be notified for an event – OPPENED/CLOSED by (VOICE CALL) and / or via SMS on a mobile phone.
- Send pre-recorded voice massage ( for models with additional microphone included in the package ).
- By pressing a button on the caller’s phone during a call, the microphone sensitivity and speaker volume levels can be remotely adjusted.
- If a currently dialled number does not answer, the device has an algorithm allowing it to continue dialling and redialling numbers from a previously set list.
- The trigger time can be set for each input.
- 1 output can be used for call visualisation by connecting an LED.
- In the event of a power failure, the output maintains the last state it was in, resuming it once power is back on.
- Digital output which can initiate a phone call and/or SMS when triggered.
- Report via SMS for inputs and outputs position supply voltage level, battery level and GSM signal level.
- Ability to measure mobile network quality in real-time with the goal of choosing the best position for the antenna.
- Ability to remotely change volume levels and microphone sensitivity settings during call by pressing a button on the calling phone.
- Ability of two-way voice communication with the service for installation, repair and maintenance of the barrier/door in case of emergency
Technical Parameters
- Power Supply:
9 ÷ 30VDC
- Digital Inputs:
2 inputs (positive, negative)
- Digital outputs:
2 outputs (open collector, 1A max)
- GSM module:
850/900/1800/1900MHz
- Consumption in IDLE mode:
15mA
- Power Consumption while transmitting:
130mA
- Operational Temperature:
-40˚C ÷ +85˚C
- Weight:
90g
- Dimensions:
74mm х 64mm х 28mm
NOTES:
- For models with additional microphone, built-in speaker and included battery:
- Power Output:
12 VDC
- Internal battery for autonomous operation
3.7V/300mAh Li-ion battery, allowing emergency connection up to 60 min. call and 12h in Standby mode
- Microphone input:
1 input.
- For morе information see here: тук
Included in the package
- 1 x Smart Dialer in a plastic box
- 1 x GSM antenna with a 3 m cable
 |
 |
Downloads
Smart Dialer IoT Quick Installation
Smart Dialer IoT Full Installation
